TSR Plus Hydraulic Tensioners

TSR Plus Hydraulic Tensioners
TSR Plus Hydraulic Tensioners
Send Inquiry
Product Code : 01
Price And Quantity
  • Minimum Order Quantity
  • 1 Number,
  • Price
  • 250000 INR/Number
Product Specifications
  • Color
  • Gray
  • Product Type
  • TSR Plus Hydraulic Tensioners
  • Body Material
  • Steel
  • Type
  • Other
  • Force
  • Power kilogram-force (kgf)
Product Description

Backed by rich industry experience, we are involved in providing TSR Plus Hydraulic Tensioners. These are suitable for the oil and gas industry. TSR Plus Hydraulic Tensioners are available in different specifications as per the needs of customers. Our offered tensioners are compatible with metric bolts from M20 M100. Our offered tensioners are basically designed to fit standard flanges and single twin port options.

Product details

Bolt Diameter

M20mm

Hydraulic Area

160 kN

Hydraulic Oil Type

ISO 32 or equivalent

Stroke

10mm (0.375") except TSR+ 0 - 8mm (0.315")

Tensioner Design

Single acting cylinder, auto return

Total Tool Weigh

1 Kg

Max. Pressure

1500 bar

Brand

Boltight



Trade Information
  • Supply Ability
  • 100 Number, Per Week
  • Delivery Time
  • 4-8 Week
  • Main Domestic Market
  • All India
